Sync Android drawable assets from Figma to GitHub via PR (multi‑density PNG)

This n8n workflow automatically fetches design assets (icons, buttons) from Figma, exports them into Android drawable folder formats based on resolution (e.g., mdpi, hdpi, etc.) and commits them to a GitHub branch, creating a Pull Request with all updates.

Who’s it for

• Android / Flutter developers managing multiple screen densities.
• Design + Dev teams wanting to automate asset delivery from Figma to codebase.
• Mobile teams tired of manually exporting assets, resizing, organizing and uploading to GitHub.

How it works

1. Execute Flow manually or via trigger.
2. Fetches all export URLs from a Figma file.
3. Filters out only relevant components (Icon, Button).
4. Prepares Android drawable folders for each density.
5. Merges components with folder mapping.
6. Calls Figma export API to get image URLs.
7. Filters out empty/invalid URLs.
8. Downloads all images as binary.
9. Merges images with metadata.
10. Renames and adjusts file names if needed.
11. Prevents duplicate PRs using conditional checks.
12. Commits files and opens a GitHub Pull Request.

How to set up

1. Set up your Figma token (with file access)
2. Get Figma File Key and desired parent node ID
3. Connect your GitHub account in n8n
4. Prepare a GitHub branch for uploading assets
5. Add your drawable folders config
6. Adjust file naming logic as per your code style
7. Run the workflow

Requirements

Tool

Purpose

Figma API Token

To fetch assets and export URLs

GitHub Token

To commit files and open PR

n8n

Workflow automation engine

Figma File Key

Target design file

Node Names

Named like Icon, Button

How to customize

• Add more component types to extract (e.g., Avatar, Chip)
• Change drawable folder structure for other platforms (iOS, Web)
• Add image optimization before commit
• Switch from branch PR to direct commit if preferred
• Add CI triggers (e.g., Slack notifications or Jenkins trigger post-PR)

Add‑ons

• Slack Notification Node
• Commit summary to CHANGELOG.md
• Image format conversion (e.g., SVG → PNG, PNG → WebP)
• Auto-tag new versions based on new asset count

Use Case Examples

• Auto-export design changes as Android-ready assets
• Designers upload icons in Figma → Devs get PR with ready assets
• Maintain pixel-perfect assets per density without manual effort
• Integrate this into weekly design-dev sync workflows

Common Troubleshooting

Issue

Possible Cause

Solution

Export URL is null

Figma node has no export settings

Add export settings in Figma for all components

Images not appearing in PR

Merge or file name logic is incorrect

Recheck merge nodes, ensure file names include extensions

Duplicate PR created

Condition node not properly checking branch

Update condition to check existing PR or use unique branch name

Figma API returns 403/401

Invalid or expired Figma token

Regenerate token and update n8n credentials

GitHub file upload fails

Wrong path or binary input mismatch

Ensure correct folder structure (drawable-mdpi, etc.) and valid binary

Assets missing certain resolutions

Not all resolutions exported in Figma

Export all densities in Figma, or fallback to default

---

Need Help?

If you’d like help setting up, customizing or expanding this flow, feel free to reach out to our n8n automation team at WeblineIndia!

We can help you:

• Fine-tune Figma queries
• Improve file renaming rules
• Integrate Slack / CI pipelines
• Add support for other platforms (iOS/Web)

Happy automating!
