📥 Transform Google Drive Documents into Vector Embeddings

Automatically convert documents from Google Drive into vector embeddings using OpenAI, LangChain, and PGVector — fully automated through n8n.

---

⚙️ What It Does

This workflow monitors a Google Drive folder for new files, supports multiple file types (PDF, TXT, JSON), and processes them into vector embeddings using OpenAI’s text-embedding-3-small model. These embeddings are stored in a Postgres database using the PGVector extension, making them query-ready for semantic search or RAG-based AI agents.

After successful processing, files are moved to a separate “vectorized” folder to avoid duplication.

---

💡 Use Cases

• Powering Retrieval-Augmented Generation (RAG) AI agents
• Semantic search across private documents
• AI assistant knowledge ingestion
• Automated document pipelines for indexing or classification

---

🧠 Workflow Highlights

• Trigger Options: Manual or Scheduled (3 AM daily by default)
• Supported File Types: PDF, TXT, JSON
• Embedding Stack: LangChain Text Splitter, OpenAI Embeddings, PGVector
• Deduplication: Files are moved after processing
• License: CC BY-SA 4.0
• Author: AlexK1919

---

🛠 What You’ll Need

• Google Drive OAuth2 credentials (connected to Search Folder, Download File, and Move File nodes)
• OpenAI API Key (used in the Embeddings OpenAI node)
• Postgres + PGVector database (connected in the Postgres PGVector Store node)

---

🔧 Step-by-Step Setup Instructions

1. Create Google OAuth2 credentials in n8n and connect them to all Google Drive nodes.
2. Set your source folder ID in the Search Folder node — this is where incoming files are placed.
3. Set your processed folder ID in the Move File node — files will be moved here after vectorization.
4. Ensure you have a PGVector-enabled Postgres instance and input the table name and collection in the Postgres PGVector Store node.
5. Add your OpenAI credentials to the Embeddings OpenAI node and select text-embedding-3-small.
6. Optional: Activate the Schedule Trigger node to run daily or configure your own schedule.
7. Run manually by triggering When clicking ‘Test workflow’ for on-demand ingestion.

---

🧩 Customization Tips

Want to support more file types or enhance the pipeline?

• Add new extractors: Use Extract from File with other formats like DOCX, Markdown, or HTML.
• Refine logic by file type: The Switch node routes files to the correct extraction method based on MIME type (application/pdf, text/plain, application/json).
• Pre-process with OCR: Add an OCR step before extraction to handle scanned PDFs or images.
• Add filters: Enhance the Search Folder or Switch node logic to skip specific files or folders.

---

📄 License

Creative Commons Attribution-ShareAlike 4.0 International (CC BY-SA 4.0)
Use, adapt, and share - even commercially - as long as you give proper credit and share alike.
Full License Details
